YT235

Detail

Comfort + Control + Innovation.

As with every YANMAR tractor, the true power lies in the fuel-efficient YANMAR diesel engine. That means the YT235 can do serious work with a front-end loader, a hydraulic backhoe, and three-point hitch attachments for mowing, tilling, planting, digging, plowing, and much more. With a front loader lift capacity of up to 1,300 pounds, it’s built to take on demanding jobs with ease.

Its 35 horsepower diesel engine delivers a reliable blend of strength and efficiency, while its hydrostatic transmission gives you smooth, intuitive control. This is especially useful when navigating tight spaces or switching between implements.

The advanced styling of the YANMAR YT2 Series tractors is only the beginning. The YT235 is built to help you be more efficient and productive. Every day. From easy-to-use controls to the advanced engineering under the hood, the innovation of the YT235 goes much deeper than stunning aesthetics.

Features

Performance Link Technology™
ROPS Platform
Advanced controls to ease operator workload & increase comfort
Dual hydraulic pumps
Smooth hydraulic power steering
True 3-point hitch position control
Electro hydro independent PTO with one-touch on/off

Third function valve control available and integrated into joystick.

One-piece easy open steel hood.

Skid steer style bucket attachment.

Specs & Compare

The Yanmar YT235 provides 34.2 HP of sub-compact tractor power, engineered for performance and ease of use on properties of 25 acres or more. Its hydrostatic transmission with dual-touch pedals, selectable 2WD/4WD, and Category 1 3-point hitch offer precise control for mowing, loader work, backhoe operations, and general property maintenance.

Advanced Technology Meets Practicality
With 1,300 lbs of lift capacity at the pivot pin, 27 PTO horsepower, and a durable operator-focused design with full ROPS, the YT235 delivers both comfort and capability for a variety of property tasks.

Featured Specs

Model

YT235

Gross Power: EPA Regulation HP (kW)

34.2 HP(26.1 kW)*

Overall length (with 3PH and R4 Tires)

116.9” (2,970 mm)

Overall Width (with R4 Tires)

58.3” (1,482 mm)

Overall Height (with Roll-Over Protection, and R4 tires)

89.0” (2,261 mm)

Transmission

Hydrostatic (Dual Touch Pedal)

Drive Type

2WD/4WD selectable engagement

Lift Capacity (Pivot Pin) lb. (kg)

1,300 lb. (590 kg)

Bucket Width in. (mm)

60” (1,524 mm)

PTO Power HP (kW)

27 HP (20.1 kW)

Rear PTO Speed/Engine RPM

540

Mid PTO Speed/Engine RPM

2,013

Wheel Base

65” (1,650 mm)

Front Tires (with R4)

13.6” x 16”

Rear Tires (with R4)

15” – 19.6”

3-Point Hitch

Category 1

35 HP Compact Tractor Built for Efficiency on 10 to 50 Acres
